The program includes all NEMA and IEC B-Line series cable tray, cable ladder and pan tray products.

Once the design is complete, users can output a full BOM in a PDF or Excel format.Įaton customers can download the free software online avoiding the high cost associated with creating models from scratch and time-consuming project rework. Upon loading a design, users can select their cable management type, materials and support locations to build a three-dimensional wire-frame model of the cable tray and appropriate fittings. “The innovative Tra圜AD software allows global customers to overlay cable tray designs within their existing AutoCAD construction drawings and complete an entire bill of materials (BOM) with a click of a button, resulting in a simple and accurate design.”Įaton’s B-Line series Tra圜AD software is compatible with 64-bit versions of AutoCAD 20 operating on 64-bit Windows 7 and Windows 8 operating systems. “We saw a major opportunity to cut time – and ultimately costs – at the design and bidding stages of construction projects,” said Patrick Keller, associate product manager, Eaton’s B-Line Division. The software package incorporates Eaton’s full breadth of B-Line series cable management products and assists design and build contractors and engineers in developing accurate cable tray designs which help improve overall purchasing decisions. HIGHLAND, IL - Power management company Eaton today announced the release of its B-Line® series Tra圜AD™ software, the latest version of AutoCAD® compatible cable tray design software intended to help minimize design time and associated costs.
